Enermax LIQTECH XTR 360 | 550W+ Workstation & Server AIO CPU Cooler
$290.00
The Enermax LIQTECH XTR 360mm is a professional workstation‑grade all‑in‑one liquid cooler engineered for extreme high‑TDP CPUs up to 550W+. It fully supports AMD sTR5/SP6/sWRX8/sTRX4/TR4/SP3 and Intel LGA 4677 platforms, delivering 100% IHS coverage, a magnetic rotatable digital display, EF1 high‑flow pump, patented SCT cold plate, dual‑ball bearing PWM fans, and customizable ARGB lighting. Built for 24/7 reliability in workstations, servers, rendering clusters, and HPC environments.
Enermax LIQTECH XTR 360 | 550W+ Workstation & Server AIO Cooler
| Component | Parameter | Details |
|---|---|---|
| Model | ELC‑LTXTR360 | Enermax LIQTECH XTR 360mm Workstation/Server AIO Liquid Cooler |
| Supported Sockets | Intel LGA 4677; AMD sTR5/sTRX5/sWRX9/SP6/sWRX8/sTRX4/TR4/SP3 | For Xeon W/Scalable & Threadripper Pro |
| Cooling Capacity | 550W+ TDP | Extreme high‑TDP workstation cooling |
| Cold Plate Material | Pure Copper | Patented Shunt‑Channel Technology (SCT) |
| Radiator Material | Aluminum | High‑density fin design |
| Radiator Dimensions | 394 × 120 × 27 mm | 360mm standard form factor |
| Pump Model | EF1 Pump | High‑flow professional pump |
| Pump Speed | 700 – 3000 RPM ±10% | PWM adjustable |
| Pump Flow Rate | 450L/h | ~7x higher than standard AIO pumps |
| Pump Bearing | Ceramic Nano PI Bearing | Ultra‑low friction, long life |
| Pump MTBF | ≥100,000 hours | 24/7 server‑grade reliability |
| Pump Voltage | 12V DC | Standard server/desktop power |
| Pump Current | 0.4A; RGB: 0.24A | Efficient power draw |
| Fan Model | Dual‑Ball Silent PWM Fan | 120×120×26.8mm |
| Fan Speed | 500 – 3000 RPM ±10% | With reducer: 2400 RPM ±10% |
| Fan Air Flow | 87.9 CFM; With reducer: 76.4 CFM | High airflow for heat dissipation |
| Fan Static Pressure | 3.83 mm‑H₂O; With reducer: 2.96 mm‑H₂O | Efficient through dense fins |
| Fan Noise | 32 dBA; With reducer: 26 dBA | Ultra‑quiet professional operation |
| Fan Bearing | Dual Ball Bearing | Vibration‑resistant, long life |
| Fan Connector | 4‑pin PWM | Synchronous speed control |
| Fan MTTF | ≥100,000 hours | Enterprise‑level durability |
| Special Features | Magnetic rotatable digital display, 100% IHS coverage, SCT, ARGB sync, rotatable nozzle | Smart monitoring & flexible install |
| Accessory | Premium thermal grease included | Ready for immediate installation |
| Software | Enermax Tuner | Display, monitoring, alert settings |
| OS Support | Windows 10, Windows 11 | Full monitoring functionality |
Enermax LIQTECH XTR 360mm: The Ultimate High‑End Cooling Solution for Workstations and Servers
In professional computing environments such as workstations, data centers, rendering farms, AI training clusters, and high‑performance computing (HPC) systems, CPU cooling is mission‑critical. Processors like AMD Ryzen Threadripper Pro and Intel Xeon W/Scalable series deliver exceptional computing power but generate extreme heat under sustained loads. Standard desktop coolers simply cannot handle their high TDP requirements, leading to thermal throttling, system instability, noise issues, and shortened hardware lifespans. The Enermax LIQTECH XTR 360mm Liquid Cooler (model ELC‑LTXTR360) is purpose‑built to solve these challenges. It combines industrial‑grade durability, extreme cooling capacity, smart monitoring, flexible compatibility, and quiet operation to support 24/7 continuous workloads. This cooler redefines workstation‑class cooling, making it the top choice for IT professionals, content creators, engineers, and data center operators worldwide.
Unmatched Compatibility for Enterprise & Workstation Platforms
The LIQTECH XTR 360 is engineered from the ground up to support the latest and legacy high‑end workstation and server platforms. It offers full compatibility with AMD sTR5, sTRX5, sWRX9, SP6, sWRX8, sTRX4, TR4, SP3 and Intel LGA 4677 (Xeon W & Scalable). This wide socket support covers the entire lineup of AMD Ryzen Threadripper Pro and Intel Xeon W/Scalable processors, making the cooler future‑proof and versatile for multi‑generation upgrades. The cooler features a full‑coverage cold plate that provides 100% IHS coverage for both AMD and Intel flagship CPUs, ensuring uniform heat transfer and eliminating hotspots that plague lesser coolers. The robust mounting system ensures secure, pressure‑even installation, even in vibration‑prone server chassis and rack‑mount environments.
550W+ Extreme Cooling Performance for Heavy Workloads
At the core of the LIQTECH XTR 360 is its ability to handle 550W+ TDP—a level of performance reserved for professional‑grade cooling solutions. This extraordinary capacity is made possible by three key components: the high‑efficiency EF1 water pump with 450L/h flow rate, patented Shunt‑Channel Technology (SCT) copper cold plate, and high‑density 360mm aluminum radiator. Together, they deliver consistent, non‑throttling performance for overclocked CPUs, multi‑core rendering, 3D modeling, AI training, database operations, and continuous server tasks.
Smart Magnetic Rotatable Digital Display & Real‑Time Monitoring
The LIQTECH XTR 360 features a unique magnetic rotatable real‑time status digital display on the pump head. It offers 360‑degree orientation adjustment, real‑time CPU/GPU temperature and fan speed monitoring, customizable alerts via Enermax Tuner software, and strong 3100‑gauss magnetic mounting. This feature turns the cooler into an active system monitoring tool for professional environments.
Premium Dual‑Ball Bearing Fans for Performance & Silence
The cooler includes three 120mm PWM fans with dual‑ball bearings and silent blade design. They deliver 500–3000 RPM, 87.9 CFM airflow, 3.83 mm‑H₂O static pressure, and only 32 dBA max noise. A voltage‑reduction cable is included to limit speed to 2400 RPM and reduce noise to 26 dBA. Dual‑ball bearings ensure long life and vibration resistance for 24/7 server use.
ARGB Lighting & Flexible Installation for Versatile Deployment
The LIQTECH XTR 360 features addressable ARGB lighting compatible with major motherboard sync ecosystems. The low‑profile design avoids component interference, while the rotatable nozzle head enables flexible tubing routing. Pre‑applied thermal grease and user‑friendly mounting hardware simplify deployment in any chassis.
Industrial‑Grade Reliability for 24/7 Operation
Built for uninterrupted 24/7 use, the cooler features a sealed leak‑resistant structure, 100,000+ hours MTBF for pump and fans, high‑temperature resistance, and anti‑vibration design. Every component is tested for long‑term heavy use, reducing maintenance and downtime.
Ideal for Diverse Professional Applications
The cooler excels in enterprise servers, professional workstations, HPC systems, render clusters, and industrial workstations. It stabilizes temperatures, eliminates throttling, extends hardware life, and maximizes system efficiency across all demanding workloads.
Why Choose Enermax LIQTECH XTR 360 Over Competitors?
It offers 550W+ cooling, 100% IHS coverage, magnetic digital monitoring, broad socket compatibility, patented SCT, dual‑ball fans, ARGB sync, and industrial 24/7 reliability—outperforming standard coolers and competing workstation solutions.
Conclusion
The Enermax LIQTECH XTR 360mm Liquid Cooler is the definitive professional cooling solution for AMD Ryzen Threadripper Pro and Intel Xeon W/Scalable platforms. With industry‑leading performance, full compatibility, smart monitoring, premium quality, and quiet operation, it meets strict workstation and server demands. For professionals who refuse to compromise, this is the ultimate cooling choice.
