ASRock Rack ROMED4ID-2T Deep Mini‑ITX Server Motherboard | AMD EPYC 7003/7002

• Deep mini-ITX (6.7″ x 8.2″)
• Single Socket SP3 (LGA 4094), supports AMD EPYC™ 7003 (with AMD 3D V-Cache™ Technology*)/7002 series processors
• 4 DIMM slots (1DPC), supports DDR4 RDIMM, LRDIMM, RDIMM/LRDIMM-3DS, NVDIMM-N
• 1 PCIe4.0 x 16
• 2 low-profile SlimSAS (PCIe 4.0 x8 or 8 SATA 6Gb/s), 4 SlimSAS (PCIe 4.0 x8)
• Supports 1 M.2 (PCIe4.0 x4/SATA)
• 17 SATA 6Gb/s
• 2 RJ45 (10GbE) by Intel® X550-AT2
• Remote Management (IPMI)

ASRock Rack ROMED4ID-2T Deep Mini‑ITX Server Motherboard

Overview

The ASRock Rack ROMED4ID‑2T redefines compact server computing by combining server‑grade performance, enterprise reliability, and ultra‑small Deep Mini‑ITX dimensions. Built for space‑constrained deployments including edge data centers, IoT gateways, virtualization nodes, compact NAS, and embedded industrial servers, this motherboard supports AMD EPYC 7003 (with 3D V‑Cache) and 7002 series processors, delivering up to 64 cores of server‑class computing in a 6.7″×8.2″ footprint. It integrates high‑speed DDR4 ECC memory, PCIe 4.0 expansion, dual 10GbE networking, and flexible multi‑path storage, making it ideal for businesses seeking performance‑dense, low‑power, and easily deployable server infrastructure.

Compact Deep Mini‑ITX Form Factor

Unlike standard Mini‑ITX, the ROMED4ID‑2T uses a Deep Mini‑ITX layout (170mm×210mm) to accommodate the large SP3 (LGA 4094) socket, robust power delivery, and full‑featured I/O without sacrificing expandability. This compact design fits 1U short‑depth chassis, small form factor server cases, and embedded rackmount systems, lowering deployment costs and simplifying integration in space‑limited server rooms, industrial cabinets, and remote edge sites. Despite its miniaturized build, the board retains enterprise‑grade durability, stable power regulation, and extended temperature operation for 24/7 non‑stop service.

Powerful AMD EPYC 7003/7002 Processor Support

At its core, the ROMED4ID‑2T features a single Socket SP3 (LGA 4094) supporting AMD EPYC 7003 (with AMD 3D V‑Cache) and 7002 series processors, offering up to 64 cores and 128 threads for heavy virtualization, database, cloud computing, and storage workloads. These CPUs deliver high per‑core performance, large cache capacity, and strong multi‑threaded capability while maintaining optimized power efficiency. The motherboard supports processors up to 280W TDP with robust VRM cooling, ensuring stable performance even under sustained full loads. This makes the board a top choice for users wanting server‑level performance in a compact package.

High‑Speed DDR4 ECC Memory Subsystem

Equipped with 4 DDR4 DIMM slots (1 DPC), the ROMED4ID‑2T supports RDIMM, LRDIMM, and NVDIMM‑N enterprise memory types with ECC, memory parity, and channel redundancy to prevent data errors and improve system stability. It supports up to 1TB of LRDIMM memory or 256GB of RDIMM, with frequencies up to 3200MHz, balancing speed and capacity for virtual machines, in‑memory computing, and high‑concurrency applications. ECC technology detects and fixes hardware memory errors in real time, critical for enterprise servers requiring uninterrupted operation.

PCIe 4.0 Expansion & Flexible Storage

The motherboard provides a PCIe 4.0 x16 slot supporting bifurcation (x4/x4/x4/x4) for flexible expansion of GPUs, RAID cards, NVMe storage, or network adapters. It also includes multiple SlimSAS ports: 2× SlimLine (PCIe 4.0 x8 or 8×SATA 6Gb/s) and 4× SlimLine (PCIe 4.0 x4 or 4×SATA 6Gb/s), enabling massive storage expansion. A dedicated M.2 Key M slot (PCIe 4.0 x4, 2280) supports high‑speed NVMe SSDs for OS, caching, or fast storage. With support for hardware RAID modes, the board delivers secure, scalable, and high‑performance storage for NAS, backup servers, and media centers.

Dual 10GbE High‑Speed Network

The ROMED4ID‑2T integrates dual 10GbE RJ45 LAN ports for enterprise‑grade throughput, low latency, and stable transmission. These ports support link aggregation, failover, and virtualization bridging, meeting demands for large‑file transfers, virtual machine migration, edge computing convergence, and multi‑service gateway scenarios. High‑speed networking ensures smooth I/O between servers, storage, and terminals, boosting overall system efficiency.

Enterprise I/O, Management & Stability

The board includes rich rear I/O: VGA for emergency debugging, multiple USB 3.1/2.0 ports, and clear system status LEDs. It features an integrated ASPEED AST2500 remote management controller for out‑of‑band monitoring, remote console, and firmware updates, simplifying O&M for remote and edge sites. Industrial‑grade components, reinforced power connectors, and multi‑phase VRM ensure stable operation under long‑term load. The motherboard supports IPMI, watchdog, and hardware monitoring for temperature, voltage, and fan speed, meeting strict enterprise reliability standards.

Ideal for Diverse Enterprise Scenarios

This motherboard serves multiple use cases: Edge Computing, Compact NAS/Storage Server, Virtualization/HCI, Industrial/Embedded Server, Small Business Server.

Conclusion

The ASRock Rack ROMED4ID‑2T stands out in the compact server market with Deep Mini‑ITX size, AMD EPYC 7003/7002 support, high‑speed DDR4 ECC, PCIe 4.0, dual 10GbE, and flexible storage. It delivers server‑class performance, enterprise stability, and deployment flexibility, ideal for edge computing, SMEs, industrial embedded systems, and storage servers. For users needing high density, reliability, and value, the ROMED4ID‑2T is a professional, future‑proof choice.
